TF-C6WA truck & trailer wheel alignment machine

Download: PDF

Items / Specifications Accuracy Range
Toe ±0.1 mm ±20 mm
Camber ±0.1° ±15°
King pin ±0.1° ±20°
Back angle ±0.1° ±5°
Thrust angle ±0.1° ±5°

Packing List for reference

No. Part name Quantity
1 DELL computer set (desktop or laptop optional) 1 set
2 cabinet with clamp holder 1 set
3 signal receiver (two kinds optional) 1 set
4 4 point wheel clamp 4 sets
5 measuring head with charger 4 sets
6 360 mm turntable 4 sets

No. Part name Quantity
1 storage case 1 set
2 center-line ruler with accessories 2 sets
3 DELL laptop computer 1 set
4 signal receiver 1 set
5 laser device 1 set
6 sensor head with charger 1 set
Note: Due to product improvements design, specifications are subject to change without notice.
