TF-PL412 four post car lift (two parking spaces)

Download: PDF

four post car parking lift with two parking spaces

Models / Specifications TF-PL412
Lifting capacity 2700 kg /3600 kg
Lifting height 1880 mm/2000 mm
Drive through 1900 mm
Middle of runway movable galvanized steel plate
Lock release manual unlock
Installation space 5200 × 3000 × 3300 mm
Lifting time 70S
Falling time 60S
Working voltage 220V/380V, 50Hz/60Hz, 1Ph/3Ph
Working power 2.2 KW

  1. ◆ Hydraulic-driven, steel rope lifting system;
  2. ◆ Single stage dual-cylinder lifting;
  3. ◆ High polymer polyethylene slide blocks, wear-resistance;
  4. ◆ Platform runway & ramps made of diamond steel plates;
  5. ◆ Movable galvanized steel plates in the middle;
  6. ◆ Anti-falling mechanical locks in four posts at different heights to ensure safety;
  7. ◆ Steel parts are sandblasted then anti-corrosion primer painted and top finish color coated
Note: Due to product improvements design, specifications are subject to change without notice.
